Electric Recliner Lift Chair Deltadrive Motor Actuator Replacement Kit Model 1 28 000 131 30

This is Electric Recliner Lift Chair Deltadrive Motor Actuator Model 1 28 000 131 30 Replacement. The motor used on many brands of lift chairs.The Motor can replace Okin Deltadrive Actuator Model 1 28 000 131 30 . Check Label Before Ordering.If you have any further questions. please feel free to contact us.

• Electric Recliner Lift Chair Deltadrive Motor Actuator Model 1 28 000 131 30 Replacement

• The Motor can replace Okin Deltadrive Actuator Model 1 28 000 131 30. Check Label Before Ordering

• Min install size: 15.31 inches/389mm. Stroke: 8.27 inches/210mm

• Lift Chair Power Supply Transformer Kit. Including Power Supply. AC Power Cord and Motor Cable

• Lift Chair Power Recliner Remote Hand Control with 2 Button 5 pin Connection



  Technical data:

  Appearance: BlackPA.silver whitealuminum

  Motor: Low-voltage DC motor24V

  Operation frequency: On 1 min/Off 8min

  Stroke: 8.27inches/210mm

  Minimum dimensions: 15.31inches/389mm

  Load: 4000N max

  Speed: 42mm/sec max

  Package included :

  1x Electric Recliner Lift Chair Deltadrive Motor Actuator Model 1 28 000 131 30 Replacement

  1x Lift Chair Power Supply Transformer Kit

  1x Lift Chair Power Recliner Hand Control with 2 Button 5 pin Connection
